X-BULL 13500 Lb Winch Load Capacity Electric Winch - 12V DC Power Supply For Off-Road Trailers, 2-in-1 Wireless Remote Control, 13500 XRS Series

specification
Product Information
Product Code:
W1218121329
Product Type:
General items
Product Name:
X-BULL 13500 lb Winch Load Capacity Electric Winch - 12V DC Power Supply for Off-Road Trailers, 2-in-1 Wireless Remote Control, 13500 XRS Series
Main Color:
black
Main materials:
stainless steel
Product dimensions
Assembly Length (in.):
23.60
Assembly Width (inches):
13.30
Assembly Height (in.):
9.60
Weight (lbs):
56.00
Package size
Length (in.):
24.00
Width (inches):
13.00
Height (in.):
10.00
Weight (lbs):
60.00
Features:
1. Synthetic rope has good bending fatigue resistance, abrasion resistance, UV protection and chemical resistance. When the rope breaks, synthetic rope is safer than steel.
2. Efficient and durable Class 3 planetary steel gears provide greater traction for the 6.0HP series motors.
3. Easy to use and turn, the handle clutch fits perfectly in your hand even with winch gloves.
4. True 3-stage planetary gears enable differential, deceleration (growth), reversal, etc. The combination of multiple planetary gear systems allows for very large gear ratios, which makes it possible to achieve coaxial deceleration (growth).
description
XRS Series 13000 lb winch
The XRS Series winch is the ideal combination of speed, innovation and performance for the user. True shifting, non-motor acceleration.

Integrated electrical control box, built-in wireless remote control, 3/8" diameter synthetic cable. The XRS Series winches exceed the most demanding standards of today's modern vehicles while offering a sleek design at an affordable price and incorporating many of the best-in-class, leading-edge features not found in other high-performance winches. It has an IP67 rating for dust and water resistance operation, as well as a durable black sand-colored plastic particle coating.

Switch to high speed to quickly pull in the synthesized rope. The extra-long wiring harness is long enough to fit any vehicle and uses a quick disconnect winch power cord.
specification
Wire Pull Force: 13,500 lbs
Motor: 6.0hp
Gear ratio: 265:1
Recommended battery: 650CCA minimum
Remote control: 2-in-1 wireless remote control
Control: Remote control switch, 12 ft (3.7 m) lead
Cable length: 9.5mm x 26m
Gear train: 3-stage planetary gears
Battery Leader: Size 2, 72" (1.83 m)
Fairlead: Aluminium Hawse fairlead
Weight: 59.5 lbs (27.0 kg)
Material: Stainless steel
Brakes: Automatic load holding brakes
Drum size: 2.52" × 8.82" (64 mm× 224 mm)
Mounting Bolt Pattern: 10.00±0.015" × 4.50±0.010" (254mm × 114.3mm)
Cable Material: Synthetic Rope
Size: 600mm× 350mm×240mm
In the box:
13500LBS DC 12V Winch × 1
Hammer Forge Hook × 1
Bolt group × 1
1 × set of cables
2-in-1 wireless remote control × 1
User Manual × 1
Aluminum Hawse fairlead × 1
